∟Phase Space and Phase Portrait

∟Motion Equations of Linear Systems

This section provides a quick introduction of motion equations of linear systems, which are first order linear differential equations of the canonical coordinates.

What Is Linear System? A Linear System is a system where motion equations are first order linear differential equations of the canonical coordinates. In this case, motion equations can be expressed in the vector form as shown below:

x' = Ax + b                            (P.12)
where:
  x is the vector of [q1, q2, ..., p1, p2, ....]
  x' is the vector of dx/dt
  A is a matrix of coefficients
  b is a constant vector

For a Linear System of a single object with 1 degree of freedom, vector x is [q, p] and x' is [q', p']. The motion equations can be expressed as:

  |q'| = |a11, a12| . |q| + |b1|
  |p'|   |a21, a22|   |p|   |b2|

Now let's look at those systems of motions presented earlier:

1. The Free Fall Motion of a single object is a linear system. The motion equations can be expressed as:

  m*g = -p'                             (P.4)
  p/m = q'                              (P.5)

In vector form:
  |q'| = |0, 1/m| . |q| + |   0|
  |p'|   |0,   0|   |p|   |-m*g|

2. An object on a spring moving horizontally is a linear system. The motion equations can be expressed as:

  kq = -p'                              (P.7)
  p/m = q'                              (P.8)

In vector form:
  |q'| = | 0, 1/m| . |q| + |0|
  |p'|   |-k,   0|   |p|   |0|

3. A simple pendulum is not a linear system, because p' is not linearly related to q:

  m*g*l*sin(q) = -p'                   (P.10)
  p/(m*l*l) = q'                       (P.11)
